E355+AR E355+N Seamless Tubes EN 10297-1

Model No.︰E355+AR E355+N
Brand Name︰E355+AR E355+N Seamless Tubes EN 10297-1
Country of Origin︰Germany
Unit Price︰-
Minimum Order︰-
Share on:

 Total 300 Related Items
Prev9899100101102Next

Product Description
E355+AR EN-10297 E355+N EN-10297 Seamless Tubes

We are Stockholder & Distributors of EN 10297-1 Seamless Steel Tubes for mechanical and general engineering purposes, technical delivery conditions Part-1 : Non-Alloy & Alloy Steel Tubes

EN 10297-1 Grade E235, E235+AR, E235+N, E275, E275+AR, E275+N, E315, E315+AR, E315+N
EN 10297-1 Grade E355, E355+AR, E355+N, E275K2, E275K2+N, E355K2, E355K2+N
EN 10297-1 Grade E460, E460K2, E460K2+N, E460K2+QT, E730, E730K2, E730K2+N, E730K2+QT
EN 10297-1 Grade C22, Din 1.0402, C22+N, C22+QT, C22E, Din 1.1151, C22E+N, C22E+QT
EN 10297-1 Grade C35, Din 1.0501, C35+N, C35+QT, C35E, Din 1.1181, C35E+N, C35E+QT
EN 10297-1 Grade C45, Din 1.0503, C45+N, C45+QT, C45E, Din 1.1191, C45E+N, C45E+QT
EN 10297-1 Grade C60, Din 1.0601, C60+N, C60+QT, C60E, Din 1.1121, C60E+N, C60E+QT
EN 10297-1 Grade 38Mn6, 38Mn6+N, 38Mn6+QT, 20MnV6, Din 1.5270, 20MnV6+AR, 20MnV6+N
EN 10297-1 Grade 20MnV6+QT, 25CrMo4, Din 1.7218, 25CrMo4+QT, 41Cr4, Din 1.7035, 41Cr4+QT
EN 10297-1 Grade 30CrMo4, 30CrMo4+QT, 34CrMo4, Din 1.7220, 34CrMo4+QT, 42CrMo4, Din 1.7225
EN 10297-1 Grade 42CrMo4+QT, 36CrNiMo4, Din 1.6511, 36CrNiMo4+QT, 30CrNiMo8, Din 1.6580
EN 10297-1 Grade 30CrNiMo8+QT, 40NiCrMo7-3-3, 40NiCrMo7-3-3+QT, C10E, Din 1.1121, C10E+A
EN 10297-1 Grade C10E+TH, C10E+FP, C10E+N, C15E, Din 1.1141, C15E+A, C15E+TH, C15E+FP
EN 10297-1 Grade C15E+N, C15R, Din 1.1140, C15R+A, C15R+TH, C15R+FP, C15R+N, 16MnCr5
EN 10297-1 Grade Din 1.7131, 16MnCr5+A, 16MnCr5+TH, 16MnCr5+FP, 16MnCr5+N, 16MnCrS5
EN 10297-1 Grade Din 1.7139, 16MnCrS5+A, 16MnCrS5+TH, 16MnCrS5+FP, 16MnCrS5+N
EN 10297-1 Grade 20NiCrMo2-2, Din 1.6523, 20NiCrMo2-2+A, 20NiCrMo2-2+TH, 20NiCrMo2-2+FP
EN 10297-1 Grade 20NiCrMo2-2+N, 20NiCrMoS2-2, Din 1.6526, 20NiCrMoS2-2+A, 20NiCrMoS2-2+TH
EN 10297-1 Grade 20NiCrMoS2-2+FP, 20NiCrMoS2-2+N Seamless Steel Tubes for Mechanical

We mainly stock the Tubes of following make :

Sumitomo Metal - Japan
Nippon Steel - Japan
JFE Steel - Japan
Kawasaki Steel - Japan
Vallourec & Mannesmann - France
Vallourec & Mannesmann - Germany
Vallourec & Mannesmann - Brazil
Salzgitter Mannesmann - Germany
Arcelor Mittal Steel - Romania
Arcelor Mittal Steel - Czech Republic
Tenaris Dalmine - Spain
Tenaris Silcotub - Romania
Tenaris Siderca - Argentina
Tenaris NKK - Japan
Volzhski - Russia
Nizhnedneprovsky - Ukraine
USS - USA
Maharashtra Seamless - India
Indian Seamless - India
Jindal Saw - India



EN 10297 - 1 : 2003   Seamless circular steel tubes for mechanical and general engineering purposes. Non-alloy and alloy steel tubes

1.0225             E275                        1.0236             E315

1.0308             E235                        1.0456             E275K2

1.0536             E470                        1.0580             E355

1.0599             E420J2                   1.0644             E590K2

1.0920             E355K2                  1.1121             C10E

1.1127             38Mn6                     1.1140             C15R

1.1141             C15E                       1.1151             C22E

1.1181             C35E                       1.1191             C45E

1.1221             C60E                       1.6511             36CrNiMo4

1.6523             20NiCrMo2-2       1.6526             20NiCrMoS2-2

1.6563             41NiCrMo7-3-2    1.6580             30CrNiMo8

1.7035             41Cr4                      1.7131             16MnCr5

1.7139             16MnCrS5             1.7216             30CrMo4

1.7218             25CrMo4                1.7220             34CrMo4

1.7225             42CrMo4                1.8891             E460K2

1.8893             E730K2





EN 10297 - 2 : 2005   Seamless circular steel tubes for mechanical and general engineering purposes. Stainless steel

1.4002             X6CrAl13               1.4006             X12Cr13

1.4016             X6Cr17                   1.4301             X5CrNi18-10

1.4305             X8CrNiS18-9        1.4306             X2CrNi19-11

1.4307             X2CrNi18-9           1.4311             X2CrNiN18-10

1.4335             X1CrNi25-21         1.4362             X2CrNiN23-4

1.4401             X5CrNiMo17-12-2                1.4404             X2CrNiMo17-12-2

1.4410             X2CrNiMoN25-7-4               1.4424             X2CrNiMoSi18-5-3

1.4429             X2CrNiMoN17-13-3             1.4435             X2CrNiMo18-14-3

1.4436             X3CrNiMo17-13-3                1.4439             X2CrNiMoN17-13-5

1.4460             X3CrNiMoN27-5-2               1.4462             X2CrNiMoN22-5-3

1.4466             X1CrNiMoN25-22-2             1.4477             X2CrNiMoN29-7-2

1.4501             X2CrNiMoCuWN25-7-4     1.4507             X2CrNiMoCuN25-6-3

1.4510             X3CrTi17                              1.4512             X2CrTi12

1.4529             X1NiCrMoCuN25-20-7      1.4539             X1NiCrMoCu25-20-5

1.4541             X6CrNiTi18-10                      1.4547             X1CrNiMoCuN20-18-7

1.4550             X6CrNiNb18-10                    1.4558             X2NiCrAlTi32-20

1.4563             X1NiCrMoCu31-27-4         1.4571             X6CrNiMoTi17-12-2

1.4580             X6CrNiMoNb17-12-2         1.4749             X18CrN28

1.4833             X12CrNi23-13                       1.4835             X9CrNiSiNCe21-11-2

1.4845             X8CrNi25-21                         1.4854             X6NiCrSiNCe35-25

1.4876             X10NiCrAlTi32-21                1.4878             X8CrNiTi18-10


Mechanical properties

ReH     Minimum yield strength

Rm      Tensile strength

A         Minimum elongation

J           Notch impact test





Heat treatment conditions

+A       Soft annealed

+AC    Annealed to achieve spheroidization of the carbides

+AR    As rolled

+AT     Solution annealed

+C       Cold drawn / hard

+CR    Cold rolled

+FP     Treated to ferrite-pearlite structure and hardness range

+I        Isothermal annealing

+LC     Cold drawn / soft

+M      Thermo mechanical rolling

+N       Normalized

+NT     Normalized and tempered

+P        Precipitation hardened

+PE     Peeled

+QA    Air quenched and tempered

+QL    Liquid quenched and tempered

+QT     Quenched and tempered

+S        Treated to improve shearability

+SH     As rolled and turned

+SR     Cold drawn and stress relieved

+T        Tempered

+TH     Treated to hardness range

+WW  Warm worked

+U       Untreated


Inspection & Approval Certificates : C/W Certificate (Calibration Works Certificate) EN 10204 3.1 / DIN 50049 3.1 / ISO 10474 3.1 Mill Test Certificate, NACE MR-0103 / NACE MR-0175 / ISO 15156, CE Marked, European Pressure Equipment Directive PED-97/23/EC, AD-2000-WO, ASME Boiler & Pressure Vessel Code Sec.II Part A Ed. 2008, API 6A (American Petroleum Institute), with 3.2 certificate duly Certified & Approved by LRS (Lloyd's Register), GL (Germanischer Lloyd), BV (Bureau Veritas), DNV (Det Norske Veritas), ABS (American Bureau of Shipping), SGS, TUV, RINA, IRS, NORSOK Approved Standard M-630, M-650 Rev.3

If you have any requirement of above items, please feel free to contact us
